HP ZBook 15u G5 – Full Specification

General

Model: HP ZBook 15u G5 Mobile Workstation

Processor: Intel Core i7-8565U (8th Generation Whiskey Lake)

Quad-Core

Base Clock: 1.8 GHz

Turbo Boost up to 4.6 GHz

8 MB Cache

Operating System: Windows 10 Pro (64-bit) or Windows 10 Home (depending on configuration)

Memory (RAM)

Installed RAM: 16 GB DDR4

Memory Speed: 2400 MHz

Memory Type: DDR4 SDRAM, SODIMM

Maximum Memory Supported: Up to 32 GB (2x 16GB slots)

Storage

Primary Storage: 512 GB PCIe NVMe M.2 Solid State Drive (SSD)

Additional Storage Options: Available with optional secondary drive bay in some configurations

Graphics

Integrated Graphics: Intel UHD Graphics 620 (integrated with CPU)

Discrete Graphics: Optional AMD Radeon Pro WX 3100 (2GB GDDR5) dedicated GPU

Display: 15.6-inch diagonal display

Resolution options: Full HD (1920 x 1080) IPS, Anti-glare or Touchscreen variants available

Brightness: Approx. 250-300 nits (depending on panel)

Display Features

Anti-glare, LED-backlit, IPS

Optional touchscreen available

72% NTSC color gamut (depending on panel)

Audio

Bang & Olufsen audio with dual speakers

HD audio

Integrated microphone array

Camera

HD webcam (720p)

Optional IR camera for Windows Hello facial recognition (in some configurations)

Connectivity

Wireless:

Intel Dual Band Wireless-AC 9560 (802.11ac) Wi-Fi and Bluetooth 5 combo

Wired:

Gigabit Ethernet (RJ-45) port

Ports:

2 x USB 3.1 Gen 1 Type-A ports

1 x USB Type-C with Thunderbolt 3 support

1 x HDMI 1.4b

1 x Mini DisplayPort 1.4

Headphone/microphone combo jack

Smart card reader (optional)

SD card reader (optional)

Keyboard & Input

Full-size, spill-resistant keyboard

Backlit keyboard option available

Precision touchpad with multi-touch gestures

Battery

3-cell, 50 Wh Li-ion battery

Battery life: Up to 10-12 hours (varies based on usage)

Supports fast charging

Dimensions & Weight

Dimensions (W x D x H): Approx. 364 x 251 x 19.9 mm (14.33 x 9.88 x 0.78 inches)

Weight: Starting at approx. 1.81 kg (4.0 lbs), varies with configuration

Security Features

HP Sure Start Gen4 (BIOS protection)

TPM 2.0 (Trusted Platform Module)

Fingerprint reader (optional)

HP Client Security Suite

BIOS-level security

Additional Features

MIL-STD 810G tested for durability

Energy Star certified

Dual array microphone for better voice clarity
